Smallest Car GPS TrackDevice Cut Off Fuel Of The Car With Internal Antenna
Product advantages:
Small size, size: 83mm * 54mm * 26mm, weight 120g, easy to hide.
Support positioning without positioning server conditions: real-time latitude and longitude / time / speed, the use of public map software, by manually entering latitude and longitude can query real-time location information
If you are looking for a target to enter an underground car park or other GPS blind area, the tracker will report to you the location of the last targeted location.
Text geography information service
Remote oil off power
Timing tracking function.
SMS remote restart, reset button to restart
Input power: 12V-24V DC
GSM / GPS signal indicator
Authorization number add / delete function.
Has a hidden alarm function.
Electronic fence, you can set a fixed area, beyond the fixed area that alarm.
External power off alarm.
Door open alarm
Illegal ignition alarm
Shift alarm: when the vehicle stays down when the fortification, once the shift can be authorized to the police **** police.
Speed alarm: can be set to monitor the target at a certain speed travel, more than this speed can alarm.
Low power alarm function.
This Mini Size GPS Tracking Units model CA-V4 is our newest model, the size is like a lighter, very easy to hidden when install, and 9-100V widly working voltage makes it can widly used in motorbike, Electric bike, car, trucks etc. Meanwhile, The price is also very competitive, this small unit is very suitalbe for largely quantity marketing. If you are a wholesale or GPS Tracker distributor, this is very suitable model for you.
Performance Parameters:
| Content | Specs. |
| Name | Motorcycle GPS Tracker |
| Network | 2G GSM GPRS |
| Band | 850/900/1800/1900Mhz |
| GPS chip | UBLOX |
| GPS sensitivity | -159dBm |
| GPS accuracy | 10m |
| Time To First Fix | Cold status 38s Warm status 15s Hot status 1s |
| voltage input | 9－100V input |
| Battery | Build-in 3.7V 140mAh Li-ion battery |
| Storage Temp. | -40°C to +85°C |
| Operation Temp. | -20°C to +55°C |
| Humidity | 5%--95% non-condensing |
| Size | 7.6cm x 2.6cm x 1.3cm |
| Weight | 0.067kg ( Battery and Power cord Included ) |
| Waterproof | IP67 |
Car GPS Tracker Mini GSM GPRS Motorcycle GPS Tracking Device Cut Off Engine Stop Car
Based on GSM / GPRS (850/900/1800 / 1900MHZ) wireless communication network and GPS satellite positioning system, a variety of ways to implement tracking, free monitoring center software, covering the global map, real-time computer tracking; mobile phone query map; GOOGLE EARTH tracking.
◆Installation diagram of The Tracker
◆GPS Vehicle Tracker Installation
GPS tracker should be installed by technical professional of local service centre. Without permission, the user cann’t repair and move the tracker randomly. If users do, any unfortunated damage should be compensated by himself.
Installation steps (caution: the following installation should under no power, otherwise will be dangerous)
1.Power supply line: The red wire connects 12V“+”;Black wire connects to 12V“-”
2. Wire for cutting off oil of the tracker
Yellow wire connects the relay pin 86; 85 pin connect to 12 V DC , 87a pin and 30 pin in series power supply circuits. Caution: Wrong connection of yellow wire will damage the tracker.
3. Wire for cutting off circuit of the tracker
White wire connects relay pin 86; 85 pin to 12 V DC, 87a pin and 30 pin are in series power supply circuits. Caution: Wrong connection of yellow wire will damage the tracker.
4. Emergency triggering alarm
The blue wire connects the positive of the alarm button, and the black wire connects the negative of the alarm button.
◆Application
- Vehicle Rental/Special Tracking System
- Finance and Insurance Business Tracking System
- Car Commanding and Dispatching System
- Heavy Construction Vehicles Tracking Device
- Shipping Cargoes Tracking
