High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking
Parameter
| GSM two-way | 850/900/1800/1900 MHz |
| GPS positioning | GPS sensitivity: -162dBm |
| GPS positioning accuracy: 5 meters (under open conditions) |
| Speed accuracy: 0.1 m/s |
| Cold start time: <38 seconds |
| Warm start time: <32 seconds |
| Hot start time: <2 seconds |
| Base station positioning | Support base station positioning, positioning accuracy: 10~200 meters |
| Working current | Average current ≈22mA (12vDC) maximum current <100mA (12VDC) |
| Operating temperature | -20~+70℃ |
| Material | Engineering plastics |
| Weight | 50G |
| Network | 4G LTE/3G WCDMA /2G GSM |
| Dim. | 90*40*15mm |
| Storage Temp. | -40°C to +85°C |
| Accuracy | 5-20m |
| Operation Temp. | -20°C to +55°C |
| Humidity | 20%--80% non-condensing |
| Working Voltage | 9-100V |
| CPU | MTK6261 |
Produce Description
| GSM | GPRS |
| Geo-sensor | Input power |
| ACC | Ignition checking |
| Built-in battery | Cutt off power/fuel |
| Real time tracking | Over speed alarm |
| Relay supported | Platform /APP supported |
High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking
Product Specification
| Frequency | North America EC25-A
EC25-V:LTE FDD: B2/B4/B12
WCDMA: B2/B4/B5
LTE FDD: B4/B13 |
| Nerworks | 4G/3G/2G |
| Battery | 200mah |
| Operating Voltage | 9-100v |
| Location time | Hot start≈2s(Open sky) |
| Location accuracy | 5-10M |
| Operating temperature | -20℃～+70℃ |
| Dimension | 90*40*15mm |
| Weight | 0.05kg |
Produce Description
| GSM | GPRS |
| Geo-sensor | Input power |
| ACC | Ignition checking |
| Built-in battery | Cutt off power/fuel |
| Real time tracking | Over speed alarm |
| Relay supported | Platform /APP supported |
High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking
Functions
| Platform | |
| up to 180 days historical route track | electronic fence, out of the regional alarm |
| deviate planning route alarm | serious collision warning (optional); |
| rollover warning (optional); | overspeed alarm |
| report output | free to use |
1. Real-Time Positioning:
C003-01-4G GPS Tracker Device will get the real-time position message and upload all status to the server system.
And will display the position on the map. you can click any of the points to know the name. locating time. and acc status. Speed
GPS Time, direction, and so on.
2. Vibration alarm:
After setting the command of vibration by SMS. When it moves there will be a vibration alarm message.
3. Power-off alarm:
If the power supply of GPS Tracker is cut off or GPS Tracker will send the alarm message to the server or bonded Phone number.
4. Remote Car Lock:
If an illegal ignition alarm receives from GPS Tracker, you can remotely cut off the vehicle circuit, so that to avoid being driven away.
High Precision 5M 4G GPS Tracker with Remote Monitor Real Time Tracking
Main components
GPS Functions:
protocol: GT06 1)support ACC ignition checking ,
G-sensor : BS250E 2)support Relay for cutting off power/fuel
input power: 9-100V 3)built-in GPS antenna: 18*18*4 mm
power IC: SL3036H 4)built-in battery, Real time tracking.
GSM module: MT6261 5)Geo-fence, over speed alarm,
GPS module: Ublox 6)platform /APP supported
Device status indicators
1 Connect DC 9-100V power supply and the red LED will light continuously.
The red LED is the power signal,
it is always on when the external DC is connected.
2 The blue LED is the GSM signal indicator.
It is always on when there is no GSM
it flashes when GSM is normal;
it flashes quickly when transmitting data.
3 The yellow LED is the GPS signal indicator:
it is always on when there is no positioning;
it flashes after positioning.
