Real Time Car GPS Tracker Quad Band Support ACC Ignition Checking G17H

G17H Sell To Indian GPS Tracker With Cheapest Price Have Relay Fuctions

1. Specification:

2. G17H GPS Tracker Function:

G17H parameters
G-sensor : BS250E
input power: 9-90V
power IC: SL3036H
GSM module: MT6261
GPS module: TD1030

built-in battery

support ACC ignition checking ,

support Relay for cutting off the power/fuel
built-in GPS antenna: 18*18*4 mm
Real time tracking.

Geo-fence, over speed alarm, main power off alarm, vibration alarm.

3. Product Appearance:

Command list part1

Command list part 2

G17H Sell To Indian GPS Tracker With Cheapest Price Have Relay Fuctions

1. Communication Protocol

Introduction

This document defines instructions about interface protocol on application layer of vehicles GPS tracker and location-based service platform. Related interface protocol only applies in the interaction between the platform and the position terminal.

1. Basic Rules
   1. If a GPRS connection is established successfully, the terminal will send a first login message packet to the server and, within five seconds, if the terminal receives a data packet responded by the server, the connection is considered to be a normal connection. The terminal will begin to send location information (i.e., GPS, LBS information package). A status information package will be sent by the terminal after three minutes to regularly confirm the connection.

1. If the GPRS connection is established unsuccessfully, the terminal will not be able to send the login message packet. The terminal will start schedule reboot in twenty minutes if the GPRS connection is failed three times. Within twenty minutes, if the terminal successfully connects to the server and receives the data packet from the server as the server’s response to the login message packet sent by the terminal, the schedule reboot will be off and the terminal will not be rebooted; otherwise, the terminal will be rebooted automatically in twenty minutes.

1. After receiving the login message packet, the server will return a response data packet. If the terminal doesn’t receive packet from the server within five seconds after sending the login message packet or the status information package, the current connection is regarded as an abnormal connection. The terminal will start a retransmission function for GPS tracking data, which will cause the terminal to disconnect the current GPRS connection, rebuild a new GPRS connection and send a login message packet again.

1. If the connection is regarded to be abnormal, and the data packet as a response from the server is failed to be received three times after a connection is established and a login message packet or status information package is sent, the terminal will start schedule reboot and the scheduled time is ten minutes. Within ten minutes, if the terminal successfully connects to the server and receives the data packet responded by the server, the schedule reboot will be off and the terminal will not be rebooted; otherwise, the terminal will be rebooted automatically in ten minutes.

1. In case of the normal connection, the terminal will send a combined information package of GPS and LBS to the server after the GPS information is changed; and the server may set a default protocol for transmission by using commands.

1. To ensure the effectiveness of the connection, the terminal will send status information to the server at regular intervals, and the server will return response data packets to confirm the connection.

G17H Sell To Indian GPS Tracker With Cheapest Price Have Relay Fuctions

1. For the terminal which doesn’t register an IMEI number, the server will reply the terminal with a login request response and heartbeat packet response, rather than directly disconnect the connection. (If the connection is directly disconnected or the server doesn’t reply to the terminal, it will lead to a continuous reconnected by the terminal and the GPRS traffic will be consumed heavily.

Applications:

1. Bus/Police Car/Taxi
2. Container/cargo/asset tracking

G17H Sell To Indian GPS Tracker With Cheapest Price Have Relay Fuctions

Gurantee:

1. All of our product is free to use the Tracking service server in 24 hours each day
2. All of our product there is a 2 year quanlity assurance.
3. Sample fee will not be returned.


Product Configuration:

1. Standard configuration

1) Portable GPS Device 1 pcs
2) Power lines 1 pcs

car gps locator

automobile gps tracker
